How High-Voltage Vehicles Can Deliver You More

The charging speed of an EV depends on the charger’s power output, which is a combination of voltage and current. Instead of increasing the current—which causes excess heat and energy loss—higher voltage boosts charging speeds more efficiently.

February 04, 2025. By News Bureau

Tags:

articles

The electric vehicle (EV) landscape has witnessed impressive growth, particularly with scooters and electric 3 & 4 wheelers catering to eco-conscious commuters. However, most of these vehicles operate on low-voltage systems, which come with limitations in terms of efficiency, performance, and long-term durability. High-voltage electric motorcycles, on the other hand, are redefining the benchmarks of energy efficiency and delivering a superior riding experience.

Unlocking the Potential of High-Voltage EVs
High-voltage electric motorcycles stand out by optimising energy usage while delivering top-notch performance. One of the most significant advantages is the reduction in heat generation. Since high-voltage systems require lower current to deliver the same power, they generate far less heat. This improves energy efficiency and extends the lifespan of key components like the battery and motor.

Higher voltage also translates to better range. By reducing energy losses, these motorcycles make better use of stored energy, allowing riders to go further on a single charge. They also support faster charging, making long rides more convenient. The charging speed of an EV depends on the charger’s power output, which is a combination of voltage and current. Instead of increasing the current—which causes excess heat and energy loss—higher voltage boosts charging speeds more efficiently.

To illustrate, if you connect a light bulb to a low-voltage battery, it will glow dimly. When connected to a high-voltage battery, the bulb shines brighter because more power is being delivered. Similarly, high-voltage systems allow electric motorcycles to achieve faster acceleration and maintain high speeds without overloading components.

Moreover, high-voltage systems enable lighter and more compact wiring, as lower current reduces the need for heavy cables. This results in a lightweight design that not only improves aerodynamics but also enhances overall vehicle efficiency.

Increased battery voltage also boosts overall EV efficiency. For riders, this means reduced energy consumption, improved performance, and more reliable rides.

Challenges with Low-Voltage EVs
Low-voltage electric vehicles come with inherent limitations that impact their overall efficiency and performance. One primary challenge is higher energy loss, as these systems rely on higher currents to deliver the required power. This results in excessive heat generation in components such as wiring, batteries, and connectors, leading to wasted energy.

Moreover, the strain caused by high currents on electrical components significantly reduces their lifespan, contributing to reduced efficiency and higher maintenance costs over time. Another critical drawback is the limited performance of low-voltage EVs, as they struggle to balance energy consumption with acceleration, speed, and range. This makes them less suitable for users demanding consistent performance, especially during high-load operations or long rides.

Energy Loss in Low Voltage vs High Voltage
A high-voltage powertrain, such as a 240V system, significantly reduces energy losses compared to a low-voltage 56V system by minimising current flow for the same power output. For example, delivering 30 kW at 56V requires about 535A, while at 240V, it only needs 125A. This lower current in the 240V system reduces resistance-induced heat in cables by a factor of up to 18, enabling the use of thinner, lighter wires and improving efficiency. In the inverter, the reduced current cuts conduction and switching losses, simplifying cooling and increasing reliability, improving inverter efficiency from about 92 percent at 56V to 96 percent or higher at 240V. Similarly, in the motor, copper losses in the windings are dramatically reduced—what may account for 5 kW of heat loss in a 56V system could drop to 2-3 kW in a 240V system. Overall, a 240V powertrain can reduce total energy losses by up to 50 percent, making it ideal for high-performance vehicles.

The Future of High-Voltage Motorcycles
As the EV industry progresses, high voltage is emerging as a cornerstone of modern electric mobility, shaping a future that is faster, smarter, and more sustainable. High-voltage motorcycles aren’t just about speed—they’re about improving efficiency, extending range, and providing a smoother, hassle-free riding experience.

- Karthikeyan A, Co-Founder & CTO, Raptee.HV
